Radio Control  Extra Long Range 10 Miles (16 km) Control, irrigation, lighting, solar, pumps, remote monitoring

937161 1 Channel Transmitter   $498.99  Add Antenna	937164 4 Channel Transmitter   $598.99 Add Antenna	1 Channel Transmitter NEMA4 Plastic $439.99	4 Channel Transmitter NEMA4 Plastic enclosure   $539.99	21" Base Antenna   937095 $59.99
937061 1 Channel Receiver $499.99 Add Antenna	937064 4 Channel Receiver $599.99 Add Antenna	Receiver 16 Channel       937016 Add Antenna	12VDC Power Supply 931230   $59.99	3 foot Antenna Kit 937099   $79.99

---

SPECIFICATIONS Operating Voltage: 12 to 15. VDC Temperature: -4° to +140° F (-20° to +60° C) Receiver Type: 16 bit Digital -118 dB  Carrier Frequency 27 MHz  industrial band  Codes: DIP switch programming Current Drain Receiver  25 mA, standby, 65 mA operation Data Input TX  Dry contact  Relay Output 1 Amp max  30VAC N/O or N/C Antenna Z 50 Ohms Quarter Wave Antenna optional Dimensions: 24 x 19 x 9 cm / 9.5  x 7.5 x 3.5 inch Weight 8 lb. (4 Kg) each Enclosure  NEMA 4X  metallic waterproof

PERFORMANCE • 10 Miles ( 16 km ) line of sight • 2000 feet (600m) inside partially obstructed • Encoded system with 65,536 digital 16 bit codes • Transmitter Load standby 1mA, Tx 1 sec, 2.Amp • Simple DIP switch programming setup • System is Solar Ready 12VDC operation • Unlimited transmitter and receivers operation • Special applications, Upon request
